Polyester Uniaxial Gravel Driveway Geogrid
DKM – Polyester Uniaxial Gravel Driveway Geogrid also named HDPE Sheathed Polyester Composite Geogrid, it is a high strength biaxial & uniaxial geogrid for soil reinforcement of retaining wall and ground foundation,the product consisted with a biaxial or uniaxial array of composite geosynthetic strips. The strips with high tenacity polyester fibers bundlings and coated with a polyethylene sheath.
Polyester Uniaxial Gravel Driveway Geogrid offer a wide range of strengths to cater to different project needs. From light-duty applications to heavy-duty projects, we have a solution that suits your specific requirements. Our comprehensive range ensures that you can find the perfect strength for your project, providing peace of mind and long-lasting stability.
Polyester Uniaxial Gravel Driveway Geogrid combine high modulus and tensile strength with flexibility and ease of installation. With a wide range of strengths available, our systems deliver exceptional performance for various applications. Choose our professional-grade geogrid systems to achieve reliable and long-lasting Driveway that stand the test of time.
Technical Parameter Specification | ||||||||
Spec/ Items | Standard | 50-10 | 80-15 | 100-20 | 150-30 | 200-40 | 300-55 | 400-75 |
Ultimate Tensile Strength Longitudinal ≥(KN/m) |
ASTM D 6637 | 50 | 80 | 100 | 150 | 200 | 300 | 400 |
Ultimate Tensile Strength Transverse ≥(KN/m) | 15 | 15 | 20 | 30 | 40 | 55 | 75 | |
Tolearance | 10% | |||||||
Typical strain at M.A.T.S. Longitudinal Direction ≤(%) | 10.5 | |||||||
Typical strain at M.A.T.S. Transverse Direction ≤(%) | 10.5 | |||||||
Strip Reinforcement Polymer | PET | PET | PET | PET | PET | PET | PET | |
Strip Coating Polymer | PE | PE | PE | PE | PE | PE | PE | |
Strip thickness ≥(mm) | 20 | 20 | 22 | 22 | 22 | 24 | 24 | |
Strip width(Longitudinal ) | 15 | 20 | 20 | 22 | 22 | 24 | 25 | |
Grid Structure | Extruded and welded | |||||||
Materials | HDPE Sheathed strips have Polyester Yarn Composite inside | |||||||
Color | Black | |||||||
Roll Length*Width | 3.90m x 50m | |||||||
Note: The geogrid tensile strength,strip width and thickness are customized. | ||||||||
DKM – Polyester Uniaxial Gravel Driveway Geogrid also named HDPE Sheathed Polyester Composite Geogrid, it is a high strength biaxial & uniaxial geogrid for soil reinforcement of retaining wall and ground foundation,the product consisted with a biaxial or uniaxial array of composite geosynthetic strips. The strips with high tenacity polyester fibers bundlings and coated with a polyethylene sheath.
Polyester Uniaxial Gravel Driveway Geogrid offer a wide range of strengths to cater to different project needs. From light-duty applications to heavy-duty projects, we have a solution that suits your specific requirements. Our comprehensive range ensures that you can find the perfect strength for your project, providing peace of mind and long-lasting stability.
Polyester Uniaxial Gravel Driveway Geogrid combine high modulus and tensile strength with flexibility and ease of installation. With a wide range of strengths available, our systems deliver exceptional performance for various applications. Choose our professional-grade geogrid systems to achieve reliable and long-lasting Driveway that stand the test of time.
Technical Parameter Specification | ||||||||
Spec/ Items | Standard | 50-10 | 80-15 | 100-20 | 150-30 | 200-40 | 300-55 | 400-75 |
Ultimate Tensile Strength Longitudinal ≥(KN/m) |
ASTM D 6637 | 50 | 80 | 100 | 150 | 200 | 300 | 400 |
Ultimate Tensile Strength Transverse ≥(KN/m) | 15 | 15 | 20 | 30 | 40 | 55 | 75 | |
Tolearance | 10% | |||||||
Typical strain at M.A.T.S. Longitudinal Direction ≤(%) | 10.5 | |||||||
Typical strain at M.A.T.S. Transverse Direction ≤(%) | 10.5 | |||||||
Strip Reinforcement Polymer | PET | PET | PET | PET | PET | PET | PET | |
Strip Coating Polymer | PE | PE | PE | PE | PE | PE | PE | |
Strip thickness ≥(mm) | 20 | 20 | 22 | 22 | 22 | 24 | 24 | |
Strip width(Longitudinal ) | 15 | 20 | 20 | 22 | 22 | 24 | 25 | |
Grid Structure | Extruded and welded | |||||||
Materials | HDPE Sheathed strips have Polyester Yarn Composite inside | |||||||
Color | Black | |||||||
Roll Length*Width | 3.90m x 50m | |||||||
Note: The geogrid tensile strength,strip width and thickness are customized. | ||||||||
